New - Build-To-Order NEWAY VM802T | Vertical Machining Centers
Have one to sell?
ConditionNew
New
Item VM802T unit
worktable size 800×440x2 mm
31.5x17.3x2 inch
size 2-350 kg
2-771.6 lb
max load 2 rotary table
travel X/Y/Z 700/420/560 mm
27.6/16.5/22 inch
rapid reverse X/Y/Z 40/40/30 m/min
1574.8/1574.8/1181.1 ipm
spindle power Kw
12.1/14.6 hp
max spindle speed 8000 rpm
spindle torque（continue/30min） 115／140 N.m
84.8/103.2 ft.ibf
magazine capacity 24（disc） pc
net weight 11000 kg
24250.4 lb
