New REPUBLIC LAGUN MILLMATIC-III STD-F | Millers, Knee, CNC

SPECIFICATIONS:

TABLE
TABLE SIZE ----------------- 55.25 in X 10 in
T-SLOTS -------------------- 3 ON 2.50 in CENTERS
T-SLOT SIZE ---------------- .63 in
MAXIMUM WEIGHT ON TABLE ---- 750 LBS.
TRAVELS
TABLE TRAVEL X-AXIS -------- 36 in
CROSS TRAVEL Y-AXIS -------- 15.25 in
KNEE TRAVEL (MANUAL) ------- 16 in
RAM TRAVEL (MANUAL) -------- 22.19 in
HEAD
MAIN MOTOR, CONSTANT HP ---- 5 HP
VARIABLE SPEEDS, 2 RANGES -- 55 TO 4250 RPM (OPT. EVS
PROGRAMMABLE S. SPEED
4250RPM)
HEAD SWIVEL ---------------- 90 DEGREES
HEAD TILT ------------------ 45 DEGREES
DISTANCE, SPINDLE TO COLUMN- 5 TO 27 in
DISTANCE, SPINDLE TO TABLE - 0 TO 18 in
QUILL
SPINDLE TAPER -------------- R-8 (OPT #40 NST)
QUILL DIAMETER ------------- 3.38 in
QUILL TRAVEL, Z AXIS ------- 4.50 in
MACHINE CONSTRUCTIVE DIMENSIONS
COLUMN TURRET DIAMETER ----- 15 in (GRADUATED)
KNEE WIDTH ----------------- 11.50 in
KNEE TO COLUMN BEARING LENGTH 18 in
SADDLE & TABLE BEARING LENGTH 23 in
RAM & TURRET BEARING LENGTH- 19 in
RAM TOTAL ------------------ 36 in
PHYSICAL
WEIGHT --------------------- 2,950 LBS
H X W X DEPTH -------------- 104 in X 67 in X 63 in

POWER, DUAL VOLTAGE MOTORS - 230/440V (440V OPTIONAL ON
FANUC
SYSTEM) (230V OPTIONAL ON SIEMENS SYSTEMS)

FEATURES:

- HEAD EQUIPPED WITH in HIGH VELOCITY COOLING SYSTEM in
- TWO SPEED RANGES 5HP CONSTANT DRIVE, MECHANICAL INFINITE
VARIABLE SPEEDS
- SPECIAL HI PERFORMANCE TRANSMISSION BELT
- AIR BRAKE FOR SPINDLE
- THE QUILL 3 3/8 in IS HARD CHROMED W

EQUIPPED WITH:

- Machine ready for Full Automatic or Manual operation.
Program 3 Axis (X - Y - Z) with full interpolation by CNC
control or disconnect the quill and manually operate the
machine using the CNC control as Digital Read Out.
- Quick quill dis

SPECIFICATIONS SUBJECT TO VERIFICATION

OPTIONAL FEATURES:

*5 HP EVS HEAD, 0-4250 RPM, R8 - 220 volts -- $3,950.00
*5 HP EVS HEAD, 0-4250 RPM, R8 - 440 volts - $3,950.00
*IMPORTANT!! SCI Board for Analog output to control of EVS
head
- (Change RPM by CNC control) Required with EVS option for
Acu-
Rite and MillPower controls only ( Hi & Low manual change).
- $550
Machine Options
Air Power Draw Bar, (Install $100 Net) ------ $875.00
R8 Collets (11), 1/8 to ?? inch ------------------ $295.00
Collet rack for R-8 collets - 48 pcs. ------- $55.00
1 set end mill holders-#40 Taper - 7 pc - 1/8 inch, 1/4 inch,
3/8 inch,
1/2 inch, 5/8 inch, 3/4 inch, 1 inch ------------------------ $1,050.00
1 set end mill holders R8 taper - 7pc - 1/8 inch, 1/4 inch, 3/8 inch,
1/2 inch, 5/8 inch, 3/4 inch, 1 inch ------------------------ $975.00
Shell end mill adapter in R-8, ?? inch ----------- $175.00
Shell end mill adapter in R-8, 1 inch ----------- $175.00
Shell end mill adapter in R-8, 1 ?? inch --------- $175.00
Shell end mill adapter in 40# taper, ?? inch ---- $175.00
Shell end mill adapter in 40# taper, 1 inch ---- $175.00
Shell end mill adapter in 40# taper, 1 ?? inch -- $175.00
Plastic Chip Shield, table mount ------------ $160.00
#40 Taper Spindle, NMTB --------------------- $1,204.00
#40 Taper Spindle using Cat Tooling (special draw bar)
------------ $1,204.00
440 volts, 3-phase, 60 hz (only Fanuc system) others
standard
------------ $1,200.00
480 volts, 3-phase, 60 hz(all system) ------- $1,200.00
220 volts, 3-phase, 60 hz(only Siemens system) others
standard ------------------------------------- $1,200.00
Spindle Safety Guard with micro switch. (Note: When
machine
is
supplied with optional electric box.) -------- $655.00
Table mounted Chip/Splash Guard with Sliding doors in
front
-------- $1,065.00
No. 40 Collet Chuck & 15 collets, NMTB ------ -
Clamp kit: 24 studs, 6 strap clamps, block & case
------ $175.00
Drill chuck ?? ?? inch, keyless R8 arbor ---------- $325.00
Drill chuck ?? ?? inch, keyless #40 --------------- -
Lagun 6 inch angle lock swivel base vise , 8 inch opening
---------- $495.00
Lagun Riser Block, installed, 4 inch ------------ $616.00
Lagun Riser Block, installed, 8 inch ------------ $744.00
Lagun Riser Block, installed, 10 inch ----------- $1,145.00
Mist Coolant, electric ---------------------- $1,250.00
Way covers, Cross & Vertical (Install $150 NET)
----------- $980.00
Base Chip Pan, floor mounted ---------------- STD
Special paint ------------------------------- P.O.R.
Z Axis Power Feed (Type 200) (Install $100 NET)
-------- $1,245.00
Halogen work light, 110V plug-in, 3ph, 60 Hz- $275.00
Kennametal #40 ??starter inch Tooling Package #3000100 -

Special Electrics
NFPA-79 Electrics, 230/3/60 with NEMA box ?? net
IMPORTANT! (Optional for control Fagor and Acurite 3500i
and
MillPower)-Standard with Fanuc and Siemens -- $2,795.00
U.L. Approval, with sticker ---------------- $350.00

Acu-Rite Control System Options
Remote Start/Stop switch ------------------- STD
Z-axis tracking of the knee ---------------- $1,460.00
Electronic edge finder probe, 0.500 inch shank, 0.200 inch tip
------ $985.00
Start-up & training at customer USA facility (2) days
(net)
------ $3,500.00
Standard Packaging Options
Wood skid w/ machine wrapped in plastic. - net
------ $130.00
Wood skid w/ treated wood, machine treated with anti-rust
coat
over all metal surfaces and wrapped in plastic. - net
------ $367.00
Completely enclosed wood crate (treated wood), machine
treated
with anti-rust coat over all metal surfaces and wrapped in
thermal sealed foil bag. - net -------------- $2,300.00

DELIVERY: IMMEDIATE, SUBJECT TO PRIOR SALE
