Used TRANSTECTOR APEX IV 240DR | Electrical Equipment, Miscellaneous

SPECIFICATIONS:
Electrical:
* Service Voltages: 240 Vac
* Service Type: 3-Phase Delta
Max. Continuous Operating Voltage (MCOV): 275 Vac
Surge Protection:
Surge Protection Technology: SASD
Protection Modes: L-L
8/20μs Surge Current: 10 kA
Nominal Discharge Current Rating (in): 10kA
Vpl 8/20μs L-N: 660@500A
Response Time: 5ns
SCCR (Short Circuit Current Rating): 65kAIC
Environmental:
Temperature Range (Operational): -30° - 65° C
Humidity: 90% non-condensing
Installation:
Mount Type: Panel
Service Wiring Terminal: #4 - #10 AWG Terminal
Status Indication Terminal: #14-#22 AWG 3-Pin Connector
