New 2024 BODOR BODORWELDER 1500 PRO | Welders, Arc

FIBER LASER CUTTING MACHINE:





Basic Parameter:

Output Power
1500W

Working mode
Continuous/Pulsed

Dimensions
760mm×325mm×540mm

Overall weight
55KG

Operating ambient temperature range
-20℃~60℃

Operating environment humidity range
≤90%

Intelligent Function:

Self-cooling - not afraid of high temperature and extreme cold
√

Constant power continuous light output
√

Smart control
√

Laser welding process library
√

Performance:

Output power regulation range
1%-100%

Power stability
＜3%

Maximum modulation frequency
5k HZ

Indication of laser wavelength
650nm

Indication of laser power adjustable range
＜1mW

Output laser wavelength
1075nm±10nm

Laser response time
10us

Interface type
QBH

Collimation focal length
50mm

Focus focal length 150mm
150mm

Length of optical fiber cable
10m

Transmission length
Standard length 10m±0.5m

Output fiber core diameter
50um

Bending radius of optical fiber cable
175mm

Configuration:

laser head
Bodor

Laser source
Bodor

Wire feeder individually packed
Bodor

Maximum supported wire weight
25KG

Cooling method
Self-cooling

Maximum supported wire feed diameter
2mm

Control mode
Knob control

Laser protective glasses
√

Copper muzzle box
Contains 7 copper nozzle,1cutting nozzle， 1 graduated tube

Total power capacity/current
8.1KVA/21.1A

Length of optical fiber cable 5m
Optional
